组盖垫片机

  • Automatic bottle screw capping sealing closing machine
Automatic bottle screw capping sealing closing machine

Automatic bottle screw capping sealing closing machine

  • Warranty :2 years
  • Control:PLC+Touch screen
  • Production speed(bottle/min): 1200-2000
  • Material: Stainless Steel
  • 产品描述:bottle capping machine, screw cap capping machine,capping machine,lid capping machine,automatic bottle capping machine,screw capping machine,cap closing machine, cap sealing machine, bottle cap closin
  • 在线订购

The design of the machine is reference to international advanced technology.It can be used for food, pharmaceutical, daily
chemicals, pesticides, cosmetics and other industries of different bottle cover. Four speed regulating motors are used for feeding cap,nipping bottle, conveying and screw cap respectively.

The machine has a high degree of automation.When change the bottle and cap,only needs to simply adjust the machine. It can feeding caps automatically if equip with cap loading hoppe.Electric control machine,has strong stability;The positioning device is arranged.It solves the problem of difficult capping of spray head, pump head, spray pump and hand button nozzle.The capping speed can be adjustable, the tightness can be adjusted according to different bottle caps .

Model
LSN-SC150
Voltage(V/Hz)
AC 220/50 110/60
Heat sealing power(W)
1500
Bottle height(mm)
38-300
Application of cap diameter(mm)
15-17
Application of bottle diameter(mm)
35-140
Working air pressure(Mpa)
0.3-0.5
Speed(bottles/min)
20-30
Dimension(L×W×H)(mm)
800X700X1600(L*W*H)
Weight(kg)
250
