130ton injection molding machine/plastic injection moulding machine /households injection molding machine
|
ITEM
|
UNIT
|
DATA
|
|||
|
Injection Unit
|
Screw Diameter
|
mm
|
35
|
40
|
45
|
|
Screw L/D Ratio
|
L/D
|
24
|
21
|
18.7
|
|
|
Injection Volume
|
cm3
|
173
|
226
|
286
|
|
|
Shot Weight
|
g
|
158
|
206
|
260
|
|
|
Injection Pressure
|
Mpa
|
235
|
180
|
142
|
|
|
Clamping Unit
|
Clamping Force
|
kN
|
1300
|
||
|
Opening Stroke
|
mm
|
400
|
|||
|
Mould Thickness(Min-Max)
|
mm
|
160-440
|
|||
|
Space Between Tie-Bars
|
mm
|
420×420
|
|||
|
Ejector Force
|
kN
|
31.4
|
|||
|
Ejector Stroke
|
mm
|
100
|
|||
|
General
|
Motor Power
|
kW
|
13
|
||
|
Heater
|
kW
|
9.2
|
|||
|
Pump Pressure
|
Mpa
|
16
|
|||
|
Machine Dimension
|
m
|
4.7×1.25×1.85
|
|||
|
Machine Weight
|
T
|
4.3
|
|||
