Empty Bottle Bagging Machine

  • Empty bottle bagging packing machine
Empty bottle bagging packing machine

Empty bottle bagging packing machine

  • warranty: 2 years
  • Suitable: plastic bottles
  • Speed: 0-8000BPH
  • Control: touch screen+PLC
  • Product description: bottle bagging machine , empty bottle packing machine ,empty bottle bagging machine , bottle packing machine
  • INQUIRY
The automatic bagging machine is designed to pack empty plastic containers into prepared plastic bags. The packing speed can be as much as 8,000 bottles per hour, which can improve the productivity greatly and reducing labor cost at the same time. This machine can bag plastic containers ranging from 20ml to 5L. It can be in line integrated with other bottle making equipments such as blow molding machine and labeling machine, fulfilling a full automatic production line for plastic containers.
Features

High speed,high production capacity;

Big adjustable range,suitable for many products;

Wide application scope,can be connected with other machines,also can be used as a single machine;

Servo motor, Festo cylinder,SIEMENS PLC control and frequency converter


Technical Parameters:
Item Specifications Remarks
Container requirements 500ml-5L,
Ranging from 500 ml to 5L; the ratio between height and diameter should be less than 4

Packing bag size Length: 600 to 1350 mm; Width: 300 to 900 mm
Conveyor length Standard conveyor: L*W 2200mm*114.3mm Can be customized.
Conveyor height 850±50 mm Can be customized.
Air pressure 6-8 Bar Supplied by the purchaser
Power consumption 0.5KW
Output 3,000 to 4,000 per hour for 500 ml bottle

 Electric appliance of our machine (can be adjusted)
1 Main electronic parts SIEMENS/JAPAN
2 Electric protection switch SIEMENS/JAPAN
3 Circuit breaker SIEMENS/JAPAN
4 Transducer MITSUBISHI/JAPAN
5 Photo electricity switch AUTONICS/KOREA
6 Pressuresensor SMC/JAPAN
7 Motor SIEMENS/JAPAN

Our servies:

Before the order:

We will make detailed solution for you based on your requirments.

We will send you videos of our products to know more about our machines.

If you are willing to visit our factory,we will pick you up at a nearby airport/station.


After the order:

We will start to produce machines and update the progress.

Our engineer will draw the layout for you.


After-sales service:

Arrange our engineer to your factory to install machines if you need,train your employee until they can operate machines well.

Provide you 2 years warranty with spare parts 2 year free.

24 hours for engineer response (all services part 5days in customer hand by Intl' courier)
