Automatic Labeling Machine

  • Automatic bottle labeling machine
Automatic bottle labeling machine

Automatic bottle labeling machine

  • Warranty :2 years
  • Labeling Speed:20-200pcs/min
  • Accuracy of Labeling:±1mm
  • Material: Stainless Steel
  • Product description: sticker labeling machine, bottle labeling machine, automatic labeling machine, round bottle labeling machine, adhesive sitcker labeling machine,plastic bottle labeling machine, galss bottle labeling m
  • INQUIRY

The machine can simultaneously achieve two-sided circumferential surface labeling and labeling features to satisfy the flat bottles, square bottles and bottle shaped single-sided and double side labeling, the entire circumference of the cylindrical body, a half weeks labeling, widely used cosmetics industry, daily chemical industry. Optional Tape printer and inkjet printer to achieve the production date printed on the label and batch information to achieve labeling – endowed integration.

Features

1. All labeling machines are made of SUS304 stainless steel
2. Labeling machine can be equipped bottle feeding table
3. Labeling machine avoid many problems of labor labeling, skew labeling, bubble, wrinkle, irregular labeling etc
4. Labeling machine equips electric-eye to improve the precision for cutting off the label materials.

5. Labeling machine adopts equivalent PLC, positioning module, stepping motor and sensor electrical control system control.

Application

1. For label: self-adhesive labels, self-adhesive film, electronic supervision code, bar code, etc.

2. Applicable products: Requires the side plane, side sweeping surface, the circumferential surface attached label.

3. Industry: Widely used in cosmetics, daily chemical, electronics, pharmaceutical, metal, plastics and other industries.

4. Application examples: Head & Shoulders shampoo flat bottle labeling, Shell Lubricants flat bottle labeling, labeling and fresh wine.

Technical Parameters

Name
Economy Round Bottle Labeling Machine
Labeling Speed
20-200pcs/min(Depending on label length and bottle thickness)
Height of Object
30-280mm
Thickness of Object
30-120mm
Height of Label
15-140mm
Length of Label
25-300mm
Label Roller Inside Diameter
76mm
Label Roller Outside Diameter
380mm
Accuracy of Labeling
±1mm
Power Supply
220V 50/60HZ 1.5KW
Gas Consumption of Printer
5Kg/cm^2
Size of Labeling Machine
2200(L)×1100(W)×1300(H)mm
Weight of Labeling Machine
150Kg
