  • Automatic Extrusion blow molding machine for pc water bottle
Automatic Extrusion blow molding machine for pc water bottle

Automatic Extrusion blow molding machine for pc water bottle

  • Warranty :2 years
  • Control:PLC+Touch screen
  • Feature:High quality
  • Automatic Grade:Automatic
  • 产品描述:blow molding machine,Extrusion blow molding machine,Automatic blow molding machine,blow molding machine for pc bottle,blow molding machine for water bottle,water bottle blow molding machine,pc bottle
  • 在线订购

Automatic Extrusion blow molding machine for pc water bottle

Parameters
Units
LSN90S
LSN100D
Material
PE,PP,PV,PVC,PA
PE,PP,PV,PVC,PA
Number of die head
set
1,2,3,4
1,2,3,4
Max Container capacity
30L
30L
Screw diameter
mm
90
100
Screw L/D ratio
-
28
28
(50HZ)Screw rpm(50hz)
r/min
10-70
10-60
(PE)Extrusion capacity per hour
kg/h
160
200
Number of heaters
-
4
5
Opening stoke
mm
900
900
Platen size
mm
500*540
500*540
Clamping force
KN
170
170
Dry cycle time
s
6
9
Air pressure
Mpa
0.8
0.8
Compressed air comsumption
m3/min
4
6
Machine dimension(L*W*H)
mm
5000*2900*3950
5200*4700*4000
Machine net weight
T
9.5
16
Extruder heating power
kw
22
27
Hydraulic motor
kw
18.5
18.5
Total power
kw
106
121
