全自动吹瓶机

  • High Speed 1L 2L 5L 20L Plastic PP HDPE Bottle Barrel Jerrycan machinery Single Double station extrusion blow moulding machine
High Speed 1L 2L 5L 20L Plastic PP HDPE Bottle Barrel Jerrycan machinery Single Double station extrusion blow moulding machine

High Speed 1L 2L 5L 20L Plastic PP HDPE Bottle Barrel Jerrycan machinery Single Double station extrusion blow moulding machine

  • Warranty :2 years
  • Control:PLC+Touch screen
  • Feature:High Productivity
  • Automatic Grade:Automatic
  • 产品描述:blow moulding machine,extrusion blow moulding machine,Double station extrusion blow moulding machine,Double station blow moulding machine,Jerrycan blow molding machine, HDPE Bottle blow molding machin
  • 在线订购

High Speed 1L 2L 5L 20L Plastic PP HDPE Bottle Barrel Jerrycan machinery Single Double station extrusion blow moulding machine

Parameters
Units
LSN90S
LSN100D
Material
PE,PP,PV,PVC,PA
PE,PP,PV,PVC,PA
Number of die head
set
1,2,3,4
1,2,3,4
Max Container capacity
30L
30L
Screw diameter
mm
90
100
Screw L/D ratio
-
28
28
(50HZ)Screw rpm(50hz)
r/min
10-70
10-60
(PE)Extrusion capacity per hour
kg/h
160
200
Number of heaters
-
4
5
Opening stoke
mm
900
900
Platen size
mm
500*540
500*540
Clamping force
KN
170
170
Dry cycle time
s
6
9
Air pressure
Mpa
0.8
0.8
Compressed air comsumption
m3/min
4
6
Machine dimension(L*W*H)
mm
5000*2900*3950
5200*4700*4000
Machine net weight
T
9.5
16
Extruder heating power
kw
22
27
Hydraulic motor
kw
18.5
18.5
Total power
kw
106
121
